100M KVM EXTENDER MANUAL
Introduction
LINK-MI LM-101TRC KVM Extender is one of our independent development products. The newest promoted KVM Extender has high quality of imagine, remote keyboard and mouse action does not have the time delay. It may widely apply in the computer, monitor, security, multimedia teaching systems and so on. It could extend keyboard, mouse and video ports on computer up to 100m.It promotes the function of anti-thunder and antijamming to make sure the security and stability.
Features
1.Ideal solution for digital signage applications.
2.Supports local and remote VGA monitors.
3.Supports resolutions to 1920*1440.
4.Sharpest and clearest VGA quality over CAT5/UTP-STP cable of any manufacturer.
5.Built-in lightning and ESD surge protection.
6.Available with optional stereo audio.
7.Use in-house CAT5/5e/6 phone wiring to locate a monitor remotely.
8.Optional VESA mounting bracket is available for mounting the remote unit to the back of a flat panel monitor.
Specification
| input connector |
1-ch VGA+ 1-ch USB |
| output connector |
VGA, 2-PS2 |
| local output |
HD15PIN ( VGA ) |
| The best resolution |
1024x768 |
| bandwidth |
350MHZ |
| input level range |
0.5-2.0Vp-p |
| input level error |
less than 3mV |
| input impedance |
75Ω |
| output impedance |
75Ω |
| echo ullage |
-30dB@5MHz |
| Max DC compensation |
±5mV-0 |
| SNR |
60dB |
| Connector standard |
HDB15, USB, Mini-DIN6, RJ45, ps2 |
| Video standard |
VGA, SVGA, XGA, SXGA, UXGA, LCD |
| Cable standard |
CAT5, CAT5E, CAT6 UTP |
| Power adapter |
DC12V/1A |
| operational temperature |
-25℃~+70℃ |
| deposited temperature |
-40℃~+80℃ |
| relative humidity |
0~95%(non-condensing) |
| MTBF |
>30000 hours |
Connection Diagram
Panel Description
